Mictrack 4G GPS Tracker MT600 Feedback

Mictrack5 years ago

Hi ALL, I am the engineer from Mictrack and we found a lots of clients use Traccar and have trouble for 4G GPS tracker MT600.

Leave us any issues you meet, we will help you check, thanks.

Mictrack5 years ago

Q: What's the port of MT600 on Traccar:
A: 5030

Q: Insert the SIM Card to MT600 but it will reboot every 2mins.
A: Pls setup your local APN

Q: Why the "CHG" LED no light?
A: it will auto-charging when backup battery voltage is less then 3.3V and LED light, or LED no light.

Q: The Protocol is open for user?
A: Yes.

Q: SMS Working fine but can not connect to Traccar server?
A: APN have not set or set wrong, please call your sim card provider to confirm.

turbo815 years ago

Hi

Can MT600 be charge using micro USB rather than hardwire?

Thanks
W

Mictrack5 years ago

Hi

MT600 do not support charge by USB port because it's main use for Vehicle.
the USB is for upgrade/Config and debug.

Thanks,
Mictrack

prime1235 years ago

Hihi:

I want to order a few 4G GPS tracker MT600-E model as my network stop GSM2G network.
I am currently using Meitrack MVT600 with the A21 LCD screen.
A21 LCD on Ebay

Can your J2 port on the MT600-E support this device ?
J2 port on MT600-E

Mictrack5 years ago

Hi,

MT600 J2 is reserved for Camera and Fuel sensor, do not suport the LED.
User manal on Mictrack

Any other questions pls contact us by info@mictrack.com

Thanks,
Mictrack

prime1235 years ago

Thank you

halfnhalf5 years ago

Hi,I have Mictrack MT500-G.
but now my MT500-G cannot update location information on traccar ver3.9....

This is sample data from tracker-server.log (The numbers in the IMEI part have been changed. e.g. xxxx1234 > xxxx3030)

2017-04-16 02:15:59 DEBUG: [742DE655: 5030 < 119.242.250.123] HEX: 23383631303735303236303030303030230d0a2330303030234155544f23310d0a233030326334393638303435244750524d432c3030313535362e30302c412c333534322e313536392c4e2c31333933382e393831342c452c372e33382c3138352e37312c3136303431372c2c2c412a35350d0a23230d0a
#861075026000000#
#0000#AUTO#1
#002c4968045$GPRMC,001556.00,A,3542.1569,N,13938.9814,E,7.38,185.71,160417,,,A*55
##

Do you have any good ideas? thank you.

Anton Tananaev5 years ago

Looks like the format has slightly changed. I would need protocol documentation to fix the issue.

Mictrack5 years ago

Hi Anton,
the protocol is Mictrack Protocol

halfnhalf5 years ago

Hi,Anton and mictrack.

Thank you for the reply and Thank you for your help.
I am going to wait next(?) update program because it is a difficult problem for me.

Anton Tananaev5 years ago

Earlier message sample doesn't match the documentation.

halfnhalf5 years ago

Hi,Anton.

Perhaps there is a problem with the settings of my device.
It may be that a line break([CR][LF]) has entered at the GPRS name section in Mictrack protocol.
I will check the my MT500 settings.thank you.

Mictrack5 years ago

Hi Anton,

We list is the Mictrack Standard protocol.
thanks for your support.
if possible can you pls also add other model to Traccar device list: MP510G MP90
https://www.mictrack.com/products

Mictrack.

halfnhalf5 years ago

Hi,Anton and mictrack.

My MT500 problem was solved.
It seems there was a problem with my setting. I'm very sorry.
thank you for your help.

My country's mobile phone operator do not use "GPRS user name" section setting.
So my MT500's "GPRS user name" section was setting blank.
but maybe it is not "blank" ,it was probably set as a "[CR][LF]".

Now I have set the GPRS user name section to "MT500" and problem was solved.

This is the correct setting of my traccar server....
Device Name: (My favorite any name)
ID: (My device's 15 digits IMEI number)
Protocol:TLT-2h (TCP Port:5030)

This is my traccar server infomation.
PC:Orange pi one (Allwinner H3 single board computer).
OS:debian jessie (from armbian).
